Add API Key Authentication to any API

We recommend API key authentication in most API sharing scenarios, but there’s a lot to implement to use API keys successfully. Let us take away all the pain. Follow this guide to get it working in less than 5 minutes.

For this tutorial, we’ll use a public API based on the popular Rick and Morty show. We’ll quickly proxy this API and add API-Key authentication.

Note - if you’re adding authentication to an API, the origin API should also be secured so traffic can’t simply go around your gateway. We have multiple options to secure the gateway-to-origin. For this example, using a public API is easier :)

Before we start, create a new project in - this project will be the gateway that sits between your client and the Rick and Morty API


1/ Add a route to your gateway to proxy the character API

In the portal, select the Files tab and choose the Routes file. Click Add Route.


In the new route set the following properties


Note - most people follow the practice of using plurals for resources. The Rick and Morty API doesn’t do this so in this demo we’re highlighting the ability for you to transform the shape of the API. Note that the gateway path /characters maps (via the URL Rewrite) to /api/character (not plural)

2/ Add the API Key policy

In your new route, expand the Policies section. Click Add Policy and choose the API Key authentication policy.


Your route is now secured and will reject all requests that don’t present a valid API Key. Next, you’ll set up the API Consumer.

Be sure to save your changes to the Routes file (tip: you can press CMD/CTRL + S)

3/ Create an API Key Consumer


Navigate to the Settings tab and choose API Key Consumers. Click Add new consumer. In the new consumer form, enter the following data:

  • Subject: test-subject
  • Key managers: enter your e-mail that you will use to sign in to your developer portal (so you can access your own key!)
  • Metadata: {}

and click Save.

4/ Access your API Key

To get an API key you’ll need to use our developer portal (where developers come to learn about your API And get their keys). You can access your Developer Portal on the Files tab’s Getting Started file (see below).


This will open your developer portal which should look like the screenshot below. Sign in using the e-mail you entered as a “Key manager” previously.


You'll need to sign in to the developer poral - note this is a separate identity from how you log in to Zuplo itself. So if you created an account with your e-mail address, you'll need to sign-up for the developer portal again. Once signed-in, you should see an API Keys section under Authentication:


You’ll see your test-subject, and notice that there are no keys. Click Create Key to create your first key 👏.


Note your consumers can create multiple keys to support flexible rolling of keys.

Scroll down to the route you created called Get all characters method and select your key in the Choose a key dropdown.


You’ll notice that the code sample on the right automatically updates to use the key you selected! You can copy it to the clipboard and curl the request using your terminal.

You can also try using the built-in test client (shown below) setup your request as shown and add a header of the form authorization: Bearer <API_KEY>.


🎉 Congratulations, you added API key authentication to an API 🥳
