Creating SOAP APIs in Python

SOAP APIs are still widely used in industries like finance and enterprise systems for their reliability and security. Even with the rise of REST APIs, SOAP remains essential for standardized and secure communication. This guide focuses on how to create and manage SOAP APIs using Python libraries like Zeep and Spyne.

Key Takeaways

  • SOAP Basics: SOAP uses XML for messaging with components like Envelope, Header, Body, and Fault.
  • WSDL Files: Act as a contract defining operations, endpoints, and data formats.
  • Python Tools: Libraries like Zeep simplify consuming SOAP services, while Spyne helps build them.
  • Setup: Install Python, Zeep, and optional features like WS-Security and asyncio.
  • Deployment: Tools like Zuplo streamline SOAP API management with features like security policies, rate limiting, and real-time monitoring.

SOAP Fundamentals and Setup Requirements

Here's an overview of the main components and tools you'll need to work with Python SOAP APIs.

SOAP Message Structure

SOAP messages are XML-based and consist of four main parts that ensure standardized communication:

ComponentPurposeRequired
EnvelopeWraps the entire message and identifies it as SOAPYes
HeaderHolds optional metadataNo
BodyContains the main request or response dataYes
FaultProvides error and status details (optional)No

Here's an example of a basic SOAP message structure:

XMLxml
<?xml version="1.0" encoding="UTF-8"?>
<soap:Envelope
  xmlns:soap="http://www.w3.org/2001/12/soap-envelope"
  xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance">

  <!-- Header (Optional): Contains metadata -->
  <soap:Header>
    <auth:Credentials xmlns:auth="http://example.org/auth">
      <auth:Username>user123</auth:Username>
      <auth:Password>pass456</auth:Password>
    </auth:Credentials>
    <tx:TransactionID xmlns:tx="http://example.org/transaction">
      TX-12345
    </tx:TransactionID>
  </soap:Header>

  <!-- Body: Contains the actual request/response data -->
  <soap:Body>
    <m:GetStockPrice xmlns:m="http://example.org/stock">
      <m:StockName>ACME</m:StockName>
    </m:GetStockPrice>
  </soap:Body>

</soap:Envelope>

WSDL Files and Services

WSDL, or Web Services Description Language, serves as a contract between the service provider and the consumer. These XML documents define everything you need to interact with the service, including operations, endpoints, and data formats.

A WSDL file is made up of five key elements:

  1. Types: Specifies the data structures used in messages.
  2. Message: Defines input and output parameters.
  3. PortType: Lists the operations available.
  4. Binding: Links operations to specific protocols.
  5. Service: Provides endpoint details.

Here's an example of a basic WSDL for a calculator service:

XMLxml
<?xml version="1.0" encoding="UTF-8"?>
<definitions name="CalculatorService"
  targetNamespace="http://example.org/calculator"
  xmlns="http://schemas.xmlsoap.org/wsdl/"
  xmlns:soap="http://schemas.xmlsoap.org/wsdl/soap/"
  xmlns:tns="http://example.org/calculator"
  xmlns:xsd="http://www.w3.org/2001/XMLSchema">

  <!-- Data types used by the service -->
  <types>
   <xsd:schema targetNamespace="http://example.org/calculator">
    <xsd:element name="AddRequest">
      <xsd:complexType>
       <xsd:sequence>
        <xsd:element name="a" type="xsd:int"/>
        <xsd:element name="b" type="xsd:int"/>
       </xsd:sequence>
      </xsd:complexType>
    </xsd:element>
    <xsd:element name="AddResponse">
      <xsd:complexType>
       <xsd:sequence>
        <xsd:element name="result" type="xsd:int"/>
       </xsd:sequence>
      </xsd:complexType>
    </xsd:element>
   </xsd:schema>
  </types>

  <!-- Messages for the service operations -->
  <message name="AddInput">
   <part name="parameters" element="tns:AddRequest"/>
  </message>
  <message name="AddOutput">
   <part name="parameters" element="tns:AddResponse"/>
  </message>

  <!-- Port Type (Interface) -->
  <portType name="CalculatorPortType">
   <operation name="Add">
    <input message="tns:AddInput"/>
    <output message="tns:AddOutput"/>
   </operation>
  </portType>

  <!-- Binding to SOAP protocol -->
  <binding name="CalculatorSoapBinding" type="tns:CalculatorPortType">
   <soap:binding style="document" transport="http://schemas.xmlsoap.org/soap/http"/>
   <operation name="Add">
    <soap:operation soapAction="http://example.org/calculator/Add"/>
    <input>
      <soap:body use="literal"/>
    </input>
    <output>
      <soap:body use="literal"/>
    </output>
   </operation>
  </binding>

  <!-- Service definition -->
  <service name="CalculatorService">
   <port name="CalculatorPort" binding="tns:CalculatorSoapBinding">
    <soap:address location="http://example.org/calculator"/>
   </port>
  </service>
</definitions>

Before diving into development, ensure you have the necessary tools and knowledge to work effectively with SOAP APIs.

Required Tools and Skills

Software You'll Need:

  • Python 3.x (latest stable release)
  • The Zeep library (install it with pip install zeep)
  • Tools for processing XML
  • A text editor or IDE that supports XML

Skills to Have:

  • Basic Python programming
  • A solid understanding of XML
  • Familiarity with web services
  • Knowledge of HTTP protocols

For practice, access sample WSDL files from public SOAP services or create your own. The Zeep library makes it much easier to handle SOAP web services by automatically generating Python code from WSDL files and offering a user-friendly API for calling remote methods.

Python Environment Setup

Here's how to set up your development environment for working with Python and SOAP APIs:

Python Library Installation

Start by installing Zeep and its optional features using pip:

Terminalbash
# Basic installation of Zeep
pip install zeep

# Add WS-Security support
pip install zeep[xmlsec]

# Add asyncio support
pip install zeep[async]

If you encounter issues with lxml, use this specific version:

Terminalbash
pip install lxml==4.2.5 zeep

Project Structure Setup

Organize your project directory like this:

text
soap_api_project/
├── app.py           # Initializes the server
├── controllers.py   # Handles CRUD operations
├── models.py        # Defines data models
├── views.py         # Contains SOAP service methods
└── requirements.txt # Lists project dependencies

Your requirements.txt file should include these dependencies:

text
zeep>=4.2.1
lxml>=4.2.5
spyne>=2.14.0

Environment Testing

Verify your setup with this script:

python
from zeep import Client
from zeep.transports import Transport

def test_environment():
    try:
        # Create a test client using a sample WSDL
        client = Client('http://www.webservicex.net/ConvertTemperature.asmx?WSDL')
        print("✓ Zeep installation successful")
        return True
    except Exception as e:
        print(f"✗ Environment setup issue: {str(e)}")
        return False

if __name__ == "__main__":
    test_environment()

Zeep simplifies working with SOAP APIs by automatically inspecting WSDL documents to generate the required service and type definitions. With your environment ready, you can now dive into building and interacting with SOAP APIs using Python.

Creating and Using SOAP APIs in Python

Using Zeep and Suds Clients

Zeep

Zeep is a Python library that simplifies working with SOAP services. Here's an example of setting up a basic SOAP client:

python
from zeep import Client
from zeep.transports import Transport

# Create a client instance
client = Client('http://www.soapclient.com/xml/soapresponder.wsdl')

# Make a service call
result = client.service.Method1('Zeep', 'is cool')
print(result)

To boost performance, you can add caching by configuring the transport layer:

python
from zeep.cache import SqliteCache
from requests import Session

session = Session()
cache = SqliteCache(path='/tmp/zeep-cache.db')
transport = Transport(cache=cache, session=session)
client = Client('http://www.soapclient.com/xml/soapresponder.wsdl', transport=transport)

Manual SOAP Request Creation

If needed, you can manually construct SOAP requests with Zeep:

python
from zeep import Client
from zeep.wsdl.utils import etree_to_string

# Create the client
client = Client('http://www.soapclient.com/xml/soapresponder.wsdl')

# Build the request manually
node = client.create_message(
    client.service, 'Method1',
    message='Hello',
    parameters={'param1': 'value1', 'param2': 'value2'}
)

# Convert to string and send
request_body = etree_to_string(node)
response = client.transport.post_xml(
    'http://endpoint.url',
    request_body,
    headers={'Content-Type': 'text/xml'}
)

These methods offer flexibility in handling SOAP API calls while preparing for potential errors.

Building SOAP Services with Spyne

Spyne

To create your own SOAP service, the Spyne library is a great option. Here's how to set up a basic service:

python
from spyne import Application, rpc, ServiceBase, Unicode
from spyne.protocol.soap import Soap11
from spyne.server.wsgi import WsgiApplication

class WeatherService(ServiceBase):
    @rpc(Unicode, _returns=Unicode)
    def get_weather(ctx, city):
        return f"Current weather in {city}: Sunny, 75°F"

# Create and configure the application
application = Application(
    [WeatherService],
    tns='weather.services',
    in_protocol=Soap11(validator='lxml'),
    out_protocol=Soap11()
)

# Wrap the application with WSGI
wsgi_application = WsgiApplication(application)

Error Management and Testing

Handling errors effectively is crucial in SOAP API interactions. Here’s an example of managing common exceptions:

python
from zeep import Client
from zeep.exceptions import Fault, TransportError

def safe_soap_call(wsdl_url, method_name, **kwargs):
    try:
        client = Client(wsdl_url)
        method = getattr(client.service, method_name)
        return method(**kwargs)
    except Fault as soap_error:
        print(f"SOAP Fault: {soap_error.message}")
        return None
    except TransportError as transport_error:
        print(f"Transport Error: {str(transport_error)}")
        return None

Zeep's popularity among Python developers has grown, with PyPI downloads increasing by 15% between March 2023 and April 2023, jumping from 120,000 to 138,000 monthly downloads [1].

For debugging, detailed logging can be very helpful. Here’s how to enable it:

python
import logging.config

logging.config.dictConfig({
    'version': 1,
    'formatters': {
        'verbose': {
            'format': '%(name)s: %(message)s'
        }
    },
    'handlers': {
        'console': {
            'class': 'logging.StreamHandler',
            'level': 'DEBUG',
            'formatter': 'verbose',
        },
    },
    'loggers': {
        'zeep.transports': {
            'level': 'DEBUG',
            'propagate': True,
            'handlers': ['console'],
        },
    }
})

SOAP API Management with Zuplo

Zuplo API Gateway Features

Zuplo's API gateway offers a robust solution for managing SOAP APIs. Operating across more than 300 global data centers, it delivers a typical latency of less than 50ms [4]. Zuplo's API gateway is fully programmable, allowing you to write and deploy custom functions to scale controls across your entire SOAP API, for example:

TypeScripttypescript
// Example of custom authentication logic in Zuplo
export async function validateSOAPAuth(
  request: ZuploRequest,
): Promise<boolean> {
  const soapHeader = request.headers.get("SOAPAction");
  const apiKey = request.headers.get("X-API-Key");

  if (!soapHeader || !apiKey) {
    return false;
  }

  // Validate API key using your authentication service
  return await validateApiKey(apiKey);
}

Zuplo seamlessly integrates with tools like DataDog, New Relic, and GCP Cloud Logging, providing real-time monitoring [4]. These integrations make deploying and managing SOAP APIs both fast and secure.

Zuplo Features for SOAP APIs

Feature CategoryCapabilitiesBenefits
SecurityAPI key auth, OAuth2, mTLS, IP allowlistingStrong protection for SOAP endpoints
PerformanceEdge deployment, global traffic managementLower latency and faster response times
MonitoringReal-time analytics with integrated toolsImmediate insights into API performance
DevelopmentTypeScript/JavaScript extensions, custom policiesFlexible and customizable API management

Zuplo supports backends hosted on AWS, Azure, GCP, or private infrastructure [4].

Conclusion

Summary of Key Points

Creating SOAP APIs with Python provides effective solutions for industries like finance and enterprise systems, where secure and standardized communication is crucial. This guide highlighted how Python libraries like Zeep and Spyne simplify both creating and consuming SOAP APIs [3][2].

Here's what we covered:

  • Python Tools: Libraries such as Zeep manage XML serialization and schema validation, while Spyne helps develop SOAP-based services [3][2].
  • API Deployment: Tools like Zuplo can streamline the deployment and management of your SOAP APIs.
  • Development Essentials: WSDL files serve as machine-readable documentation for your services.

These elements provide a solid starting point for implementing SOAP APIs effectively.
